MODEL SPECIFICATION
| MODEL AND SPECIFICATION | 1P 250V | 1P 250V | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Current Rating (A) | 6A | 10A | 16A | 20A | 25A | 32A | 40A | 50A | 63A | 63A | 80A | 100A | 125A |
| Max.continuous operating voltage Uc (V) | 250 | 250 | |||||||||||
| No of Poles | Single Pole | Single Pole | |||||||||||
| Frame | 63A | 125A | |||||||||||
| Breaking Capcity (Icu=75%) | 10kA | 10kA | |||||||||||
| Trip Curve | C | C | |||||||||||
| Standard | IEC 60947-2 | IEC 60947-2 | |||||||||||
| Mounting | 35mm Dinrail | 35mm Dinrail | |||||||||||
| Indication of invalidation | Tripping | Tripping | |||||||||||
Product Tags
- Single pole circuit breaker
- Circuit breaker for residential use
- 10kA breaking capacity circuit breaker
- IEC 60947-2 circuit breaker
- Overcurrent protection
- Din rail mounted circuit breaker
- C curve trip circuit breaker
- Electrical fault protection
- Overload protection breaker
- Circuit breaker for motor protection
Product Description: Single Pole Circuit Breaker (DC MCB 1P 250V)
The Single Pole Circuit Breaker is an essential component for electrical safety, providing reliable protection against overcurrent's and short circuits in electrical circuits. Designed for use in both residential and industrial settings, this breaker ensures that your electrical systems operate safely and effectively, preventing damage to devices and wiring from electrical faults.
Key Features:
•Max. Continuous Operating Voltage (Uc):
With a maximum continuous operating voltage of 250V, this circuit breaker is suitable for use in standard low-voltage electrical systems, providing dependable protection across a wide range of applications.
•Current Rating Options:
The breaker offers flexible current ratings to suit various needs, ranging from 6A to 125A. The available ratings are:
6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A, 80A, 100A, 125A.
•Frame Options:
Available in 63A and 125A frames, providing enhanced compatibility with different system designs and protection requirements.
•Breaking Capacity (Icu=75%):
This circuit breaker is capable of handling a breaking capacity of 10kA, ensuring that it can interrupt high fault currents safely without causing damage to the system.
•Trip Curve:
The breaker is designed with a C trip curve, offering medium sensitivity for general-purpose protection. It is ideal for circuits with moderate inrush currents, such as motors and general equipment.
•Standard Compliance:
Manufactured to comply with IEC 60947-2, the international standard for circuit breakers, ensuring high quality, safety, and performance.
•Mounting:
This breaker is designed to be mounted on a 35mm Din rail, making installation straightforward and compatible with standard electrical distribution panels.
•Indication of Invalidation:
The tripping mechanism provides clear indication of a fault condition, ensuring that maintenance personnel can quickly identify the issue and restore normal operation.
Additional Features:
•Compact and Space-Saving: The breaker’s design allows it to be installed in tight spaces, saving valuable panel space while providing effective protection.
•Enhanced Durability: Built to last, the circuit breaker is designed to withstand harsh conditions, ensuring a long lifespan and reliable operation.
•Low Maintenance: The device’s simple design and reliable performance minimize the need for maintenance, making it a cost-effective solution for long-term protection.
Applications:
1.Residential Electrical Systems:
Protect home circuits such as lighting, HVAC systems, and power outlets from overcurrent's and short circuits.
2.Industrial Applications:
Safeguard machinery, electrical panels, and production lines in industrial facilities, preventing damage from electrical faults.
3.Commercial Installations:
Protect electrical circuits in commercial buildings, offices, and retail spaces, ensuring the safety of critical systems and equipment.
4.Motor Protection:
Ideal for protecting motors and devices with inrush currents, such as air conditioning units and other motor-driven equipment.
5.Control Panels:
Used in control panels to provide reliable circuit protection for automated and electrical control systems.
Why Choose This Circuit Breaker?
Choose the Single Pole Circuit Breaker for your electrical protection needs, as it offers a perfect balance of reliability, safety, and ease of use. Its high breaking capacity, trip curve C, and ease of installation make it the ideal choice for residential, commercial, and industrial applications. Ensure the safety of your electrical systems and prevent costly damage caused by electrical faults with this versatile, high-performance circuit breaker.
